pp風管***點與pp風管安裝步驟

Features of PP air duct and installation steps of PP air duct

pp風管廠家一直本著以質量贏客戶的經營理念為各地客戶提供***質的管材產品，我公司生產的pp風管***點顯著，廣泛適用于建筑物室內冷熱水供應系統及采暖系統。

PP air pipe manufacturers have always been in line with the business philosophy of "quality wins customers" to provide customers with high-quality pipe products. The PP air pipe produced by our company has remarkable characteristics, which is widely used in the indoor cold and hot water supply system and heating system of buildings.

pp風管***點：

PP air duct features:

1.不銹蝕：可在很***的溫度范圍內承受PH值，范圍在1～14的高濃度的酸和堿的腐蝕。

1. No corrosion: it can withstand the corrosion of high concentration acid and alkali with pH value in a wide range of temperature, ranging from 1 to 14.

2.耐磨損、不結垢：pp風管及管件內壁均勻光滑，流動阻力小并且不結垢。

2. Wear resistance and no scaling: the inner wall of PP air duct and pipe fittings is even and smooth, with small flow resistance and no scaling.

3.減小振動和噪聲：具有******的隔聲性能，可顯著減少由液體流動引起的振動和噪聲。

3. Reduce vibration and noise: with excellent sound insulation performance, it can significantly reduce the vibration and noise caused by liquid flow.

4.防凍裂：PP材料彈性******使得管材和管件截面可隨著凍脹的液體一起膨脹而不會脹裂。

4. Anti freezing crack: PP material has excellent elasticity, so that the cross section of pipe and pipe fittings can expand with the frost heaving liquid without cracking.

5.防結露，熱損失少：PP材料為不***熱導體，可減少結露現象并減少熱損少。

5. Anti condensation and less heat loss: PP material is a poor heat conductor, which can reduce condensation and heat loss.

6.安裝簡單：重量輕，安裝操作方便，并且具有可焊性。

6. Simple installation: light weight, convenient installation and operation, and weldability.

7.使用壽命長：pp風管系統在規定的使用條件下壽命達50年。

7. Long service life: PP air duct system has a service life of 50 years under specified service conditions.

pp風管安裝步驟：

PP duct installation steps:

1、安裝pp風管時，應考慮環境溫度對安裝質量的影響，一般氣溫高于40℃或低于0℃時，不宜施工安裝。

1. When installing PP air duct, the impact of ambient temperature on installation quality shall be considered. Generally, when the temperature is higher than 40 ℃ or lower than 0 ℃, it is not suitable for construction and installation.

2、由于pp風管線膨脹系數較***，故在安裝時要考慮熱補償，一般以自然補償為主，如采用方形伸縮器。

2. Due to the large expansion coefficient of PP air pipeline, thermal compensation shall be considered during installation, which is generally based on natural compensation, such as square expansion device.

3、在架空敷設時，應對管道采用管托支承，管托可用角鋼、對剖的鋼管等材料，使增強聚丙烯在管托上可以自由伸縮。

3. When laying overhead, the pipe shall be supported by pipe support, which can be made of angle steel, split steel pipe and other materials, so that the reinforced polypropylene can freely expand and contract on the pipe support.

4、pp風管需要暗設時。建議采用管溝敷設，管子一般采用焊接連接型式，若因***殊原因需要埋地時，應采用套管形式直埋，以避免回填土內混有硬雜物，報壞管子。

4. When PP air duct needs to be concealed. It is recommended to use pipe trench laying, and the pipe is generally welded connection type. If it needs to be buried due to special reasons, it shall be directly buried in the form of casing to avoid hard sundries mixed in the backfill and damage of the pipe.

5、pp風管采用法蘭連接時，應嚴格對中，軸向***允許偏差不***于2mm，不得采用強制擰緊螺栓的方法來調整，擰緊螺栓分兩次進行，***次按對角線均勻對稱地擰一遍，然再擰緊螺栓。

5. When PP air duct is connected by flange, it shall be strictly aligned, and the maximum allowable axial deviation shall not be greater than 2mm. It is not allowed to use the method of forced tightening of bolts for adjustment. The tightening of bolts shall be carried out in two times, the first time shall be uniformly and symmetrically screwed once according to the diagonal, and then the bolts shall be tightened.
